2.5G 8 Port Copper Ethernet Switch with 10G SFP Uplink and Fanless Metal Casing for Reliable Network Performance
Detalhes do produto:
| Marca: | Takfly/DF |
| Certificação: | CE, ROHS, ISO14001, ISO9001, CPR,ANATEL,REACH |
| Número do modelo: | TK-MPO-PC |
Condições de Pagamento e Envio:
| Quantidade de ordem mínima: | 1 |
|---|---|
| Detalhes da embalagem: | embalagem internacional da exportação |
| Tempo de entrega: | 1-3 dias úteis (depende da quantidade) |
| Termos de pagamento: | TT 100% |
| Habilidade da fonte: | 3000 unidades/dia |
|
Informação detalhada |
|||
| material da bainha: | PVC | Comprimento de onda de operação: | 1310/1550nm |
|---|---|---|---|
| Perda de inserção: | 0,3dB | Intercambiabilidade: | ≤0,2dB |
| Polaridade: | Digite A, B ou C | Quantidade de fibra: | 24 |
| Modo: | SM MM | Material da virola: | Cerâmica |
Descrição de produto
2.5G 8 Port Copper Switch with 10G SFP Uplink
This 2.5G Ethernet switch features one 10G fiber uplink and eight 2.5G RJ45 ports, delivering ultra-fast connectivity without requiring existing fiber cable replacement. Equipped with an advanced chipset, it offers 2.5 times the speed of standard Gigabit Ethernet, making it ideal for performance-driven network environments.
All ports support wire-speed forwarding to ensure smooth data flow, and the plug-and-play design eliminates manual setup. The desktop-style fanless metal casing provides quiet, reliable operation, while built-in LEDs on the RJ45 ports allow for easy real-time status monitoring.
By extending Ethernet transmission over fiber links, this switch enables flexible and efficient network expansion. It works seamlessly with various 2.5G devices including computers, routers, NAS servers, printers, IP cameras, wireless access points, and other standard networking equipment. The switch is an excellent choice for medium to large enterprise networks, video surveillance systems, hotel installations, and campus networks.
Technical Features
- Provides 1 SFP fiber port supporting 1G/2.5G/10G speeds and 8 copper RJ45 ports supporting 1G/2.5G Ethernet
- Compliant with IEEE802.3 (Ethernet), IEEE802.3u (Fast Ethernet), IEEE802.3ab (Gigabit Ethernet), IEEE802.3bz (2.5G Ethernet), and IEEE802.3ae (10G Ethernet) standards
- Auto MDI/MDIX support for easy installation and system setup
- Built with high-quality, high-speed network chips using carefully selected chipset design to protect against overload, short circuits, and damage
- Supports auto MDI/MDIX crossover detection; RJ45 ports auto-negotiate 100M/1000M/2.5G speeds for true plug-and-play operation
- 10G uplink SFP fiber port supports auto-negotiation for 1G/2.5G/10G speeds with plug-and-play functionality
- Utilizes store-and-forward switching architecture with high-capacity internal buffers for non-blocking 2.5G wire-speed forwarding
- Features professional surge protection for both power and network ports
- Fanless passive cooling ensures stable operation within temperature range of -10°C to +70°C
- Supports both full-duplex and half-duplex communication with auto-negotiation capability
- All-metal housing for enhanced durability, strength, and superior heat dissipation
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Type | 2.5G Ethernet Switch |
| MTBF | 100,000 hours |
| Input Voltage | External power supply DC 12V |
| Operating / Storage Temperature | -10℃ ~ +70℃ |
| Relative Humidity | 5% ~ 95% (non-condensing) |
| Port Description | 1 x SFP fiber port (1G/2.5G/10G) + 8 x RJ45 copper ports (1G/2.5G) |
| Total Power Consumption | < 8.5W (full load) |
| Fiber Port Type | SFP |
| LED Indicators | Power, Fiber Port Status, Copper Port Status, System Status |
| Switching Mode | Store-and-Forward |
| Switching Capacity | 100Gbps |
| Packet Forwarding Rate | 74.4Mpps |
| MAC Address Table | 8K |
| Network Standards | IEEE802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3bz, IEEE802.3ae |
| Flow Control | Supported |
| Network Topology | Supports ring, star, bus, tree, and other topologies |
| Ingress Protection | IP30 |
| Housing | High-quality metal with superior heat dissipation |
| Model Number | ZSTX-GS06-2.5G1F8-SFP |
| Power Supply | External power supply DC 12V |
| Weight | 0.5kg / unit |
| Product Dimensions | 128 * 101 * 36 mm (excluding protrusions) |
| Package Dimensions | 200 * 162 * 47 mm |
| Carton Quantity | 48 units / carton |
Frequently Asked Questions
How do I place an order?
Our standard process: 1. Send us your inquiry including product name, specifications, quantity, and destination port; 2. We provide a formal quotation with lead time; 3. Upon confirmation, we issue a Proforma Invoice (PI) with bank details; 4. Production commences after receipt of payment; 5. We confirm consignee details before shipping; 6. Tracking number provided upon dispatch.
What is your MOQ?
Minimum order quantity starts from 1 piece. Pricing becomes significantly more competitive with larger volumes.
What are your payment terms?
We accept T/T, Western Union, PayPal, and MoneyGram. For large orders, we can arrange 50% deposit with balance due before delivery.
What are your lead times?
Lead times depend on product and order quantity. For standard items like fiber optic patch cords (up to 5,000 pcs), production typically takes 2-3 business days. We maintain stock for regular products and accommodate urgent requests.
Can you offer OEM/ODM services?
Yes, we accept OEM/ODM for all products and can sign a Confidentiality Agreement to protect your designs.
Are you a manufacturer?
Yes, we are a manufacturer and total solutions provider for FTTH and data center applications, founded in 2000 and based in Shenzhen, China.
Can you quote FOB prices?
Certainly. We provide FOB quotes and ship via air (DHL, TNT, UPS, FedEx) or sea for bulk orders. We provide comprehensive quotations with freight and lead time upon receiving detailed requirements.
How is your quality assured?
We adhere to IEC and European standards and hold certifications including CE, ISO, RoHS, CPR, and ANATEL. All products undergo 100% testing prior to delivery.
What is your warranty policy?
Warranty terms vary by product. Patch cords carry a standard 1-year warranty against non-artificial defects from delivery date. We also offer free repair for accidental damage; customers are responsible for associated shipping costs.
What is your packaging?
We use standard export-grade packaging. Custom logo printing is available upon request; please inform us prior to quotation.
Can I request a sample?
Yes. Samples for products valued under $10 USD are complimentary; customer is responsible for shipping costs, which must be settled prior to dispatch.
