CPR 24C Fiber Optic Patch Cord Data Center MPO Fiber Cable

Detalhes do produto:

Lugar de origem: Shenzhen, China
Marca: Neutral/OEM/Takfly
Certificação: CE/ROHS/REACH/CPR/ISO9001/ISO14001
Número do modelo: Cabo de remendo de MPO

Condições de Pagamento e Envio:

Quantidade de ordem mínima: 1
Preço: Negotiable
Detalhes da embalagem: Saco do PE
Tempo de entrega: dias 3-7working
Termos de pagamento: Western Union, L/C, T/T, Paypal
Habilidade da fonte: 100Pcs/day
Melhor preço Contato

Informação detalhada

Núcleos: 24 núcleos Tipo da fibra: Manutenção programada e milímetro
Comprimento: 1m, 3m, 5m e personalizado. diâmetro do cabo: 3,0 mm, 4,5 mm
Tipo do conector: MPO Revestimento do cabo: lszh
Cor do cabo: Amarelo, Aqua, violeta, verde-lima Aplicação: Data Center
Nome do produto: Cabo de remendo da fibra ótica MPO A outra maneira do Fanout: MTP, LC disponível

Descrição de produto

Fiber Optic MPO 24 Cores Patch Cord Data Center MPO-MPO Fiber Cable


Fiber Optic MPO Patch Cord Name:



Fiber Optic 24 Cores MPO-MPO Patch Cord



Fiber Optic MPO Patch Cord Description:

This MPO-MPO Patch Cord is for the 24 Cores, and can do it for SM and MM according to the requirements. Other cores like 8 cores, 12 cores also available.



This type cable diameter is commonly for 3.0mm, and 4.5mm diameter is also available. The MPO patch cord is with very high density, which is widely used in the Data Center with high performance.


Fiber Optic MPO Patch Cord Features:



Precision molded MT ferrule
High precision guide pins for exact alignment
Compact design, up to 4,8,12,24 fibers
IEC 61754-7 Compliant
Cable diameter 3.0mm, and 4.5mm available





Fiber Optic MPO Patch Cord Applications:

  • Telecommunication Networks
  • Active Deviced/Transceiver Interface
  • Gigabit Ethernet
  • CATV, Video and Multimedia
  • Premise Installations
  • Optical Switch interframe connections
  • Data Center

Fiber Optic MPO Patch Cord Specifications:



Item LC,SC,ST,FC.......                                  MPO/MTP
End face type PC,UPC and APC PC and APC
Fiber type SM(G652,G655,G657);MM(OM1-OM5)
Core number 12, 24
Cable Diameter 0.9,2.0,3.0 Mini Round cable:Max4.5mm; Ribbon cable:Max3.0*5.0mm
Insertion loss(dB)  ≤ 0.3 Standard:≤0.35/0.7(Typical/Max) Low Loss:≤0.2/0.35(Typical/Max)
Return loss(Min)

UPC SM:40dB

APC SM:60 dB

PC MM:25 dB

SM: APC:60dB MM: PC:20dB
Test Wavelength (nm) SM:1310/1550 MM:850/1300
Repeatability ≤ 0.1dB
Durability ≤ 0.2dB
Interchangeability ≤ 0.2dB


CPR 24C Fiber Optic Patch Cord Data Center MPO Fiber Cable 0

CPR 24C Fiber Optic Patch Cord Data Center MPO Fiber Cable 1


Why choose TAKFLY--Advantages as follows:
Professional manufacturer:

  • With more than 21 years manufacturing experience in Fiber optic products;
  • More than 450 assembly workers with 3 years experienced;
  • More than 10 R&D Engineers;
  • 16 Sets Germany imported Injection Machine and 16 Production Lines;
  • More than 30 sets of Testing Machines: OTDR,3D,VFL,IL&RL test instrument; tension strenth tester, Crush Resistance tester, Power meter tester, light checker, ect.
  • OEM Brand is acceptable.
  • Exhibition: OFC, ECOC, CommunicAsia, NETCOM, AFRICACOM, SVIAZ ICT, CommunicIndonesia ,Global Soure Electronic Exhibition,etc.

Quality Control:

  • Spot check the raw material incoming inspection before production;
  • Fully check after every individual process finished;
  • Fully check production half done;
  • Fully check the finished products before packing;
  • Spot check before shipping;

Delivery:

  • Samples: 1-3 working days.
  • Mass Production Order: 3-7 working days.
  • Packaging: Plastic Bag, Carton and Pallet are available according to your request.

Price: If your QTY is big, the price could be negotiated.
